Product Description



Downloads

ART.206100 - WL 40.zip
Technical specification
LED type
WHITE 2700K
WHITE 3000K
WHITE 4000K
WHITE 6500K
RED
GREEN
BLUE
AMBER
Number of LEDs
40 White (5W)
Lumen MAX
12500
Lenses
15°
15°x30°
25°
40°
60°
Control type
Plug-in
Input range
Universal 100 - 240 VAC; 50/60 Hz
Power (W)
100
Mounting systems
Surface
Truss (optional)
Colour finishing
Grey RAL 9006 (standard)
RAL 9006
Black RAL 9005 (optional)
RAL 9005
White RAL 9010 (optional)
RAL 9010
Marine Grade treatment
None
Yes
IP protection rating
67
Sizes l x p x h (mm)
350 x 130 x 340
Weight (Kgs)
9
