Technical specification
| Lighting source | |
|---|---|
LED type
|
WHITE 2700K
WHITE 4000K
WHITE 6500K
RED
GREEN
BLUE
AMBER
|
Number of LEDs
|
5 White (5W)
|
Lumen MAX
|
2500
|
| Optics | |
Lenses
|
4°
8°
15°
15°x30°
25°
40°
60°
|
Filters
|
None
f 17° tilt
f34° tilt
f 60°
f 65°
f 100°
f 4° x 60°
|
| Control | |
Control type
|
DMX - RDM
DMX - RDM + DALI
|
| Functions and Setup | |
Functions
|
RDM/DRS
|
| Power supply | |
Input range
|
17 VDC
|
| Physical | |
IP protection rating
|
67
68 optional
|
IK grade protection
|
08
|
Dimensions d x h (mm)
|
190 x 47,5
|
Weight (Kgs)
|
2,5
|
Materials
|
Ultra clear 10mm tempered glass
|
Mounting systems
|
Inground
|
| Finishings | |
Case
|
AISI 304 (standard)
AISI 316 (optional)
Aluminium (optional)
Aluminium - Marine Grade (optional)
|
