Technical specification
| Lighting source | |
|---|---|
LED type
|
Hi-Power NICHIA NVSW319AT
WHITE 3000K
WHITE 4000K
BIANCO 5600K
|
Number of LEDs
|
60
|
Lumen MAX
|
21000
|
| Optics | |
Lenses
|
6°
12°
12°x48°
20°
30°
45°
60°
|
| Control | |
Control type
|
Plug-in
|
| Power supply | |
Input range
|
100 - 277 VAC; 47/63 Hz
|
Power (W)
|
145
|
| Physical | |
Mounting systems
|
Surface
Truss (optional)
|
Colour finishing
|
Grey RAL 9006 (standard)
RAL 9006
Black RAL 9005 (optional)
RAL 9005
White RAL 9010 (optional)
RAL 9010
|
Marine Grade treatment
|
None
Yes
|
IP protection rating
|
65
|
Sizes l x p x h (mm)
|
362x206x320
|
Weight (Kgs)
|
8,6
|
