Product Description



Downloads

UM_MP Maxi Power series.pdf
Technical specification
LED type
Hi-Power NICHIA NVSW319AT
Number of LEDs
240
Lumen MAX
84000
Lenses
12°
12°x48°
20°
30°
45°
60°
Control type
DMX - RDM
DMX - RDM + Wireless (on request)
DMX - RDM + DALI
DMX - RDM + DALI + Wireless (on request)
Functions
RDM/DRS
Input range
100 - 277 VAC; 47/63 Hz
Power (W)
580
Mounting systems
Surface
Truss (optional)
Colour finishing
Grey RAL 9006 (standard)
RAL 9006
Black RAL 9005 (optional)
RAL 9005
White RAL 9010 (optional)
RAL 9010
Marine Grade treatment
None
Yes
IP protection rating
65
Sizes l x p x h (mm)
675 x 285 x 550
Weight (Kgs)
28
