Product Description
Downloads
Technical specification
| Lighting source | |
|---|---|
LED type
|
Hi-Power NICHIA NVSW319AT
|
Number of LEDs
|
240
|
Lumen max (lm)
|
84000
|
| Optics | |
Lenses
|
6°
12°
12°x48°
20°
30°
45°
60°
|
| Control | |
Control type
|
DMX - RDM
DMX - RDM + Wireless (on request)
DMX - RDM + DALI
DMX - RDM + DALI + Wireless (on request)
|
| Functions and Setup | |
Functions
|
RDM/DRS
|
| Power supply | |
Input range
|
100 - 277 VAC; 47/63 Hz
|
Power max (W)
|
580
|
| Physical | |
Mounting systems
|
Surface
Truss (optional)
|
Colour finishing
|
Grey RAL 9006 (standard)
RAL 9006
Black RAL 9005 (optional)
RAL 9005
White RAL 9010 (optional)
RAL 9010
|
Marine Grade treatment
|
None
Yes
|
IP protection rating
|
65
|
Sizes l x p x h (mm)
|
675 x 285 x 550
|
Weight (Kgs)
|
28
|
