Product Description



Downloads

UM_MP Maxi Power series.pdf

ART.181500 - MP 120 MAXI POWER M.zip
Technical specification
LED type
Hi-Power NICHIA NVSW319AT
WHITE 3000K
WHITE 4000K
WHITE 5750K
Number of LEDs
120
Lumen MAX
42000
Lenses
12°
12°x48°
20°
30°
45°
60°
Control type
Plug-in
Input range
100 - 277 VAC; 47/63 Hz
Power (W)
285
Mounting systems
Surface
Truss (optional)
Colour finishing
Grey RAL 9006 (standard)
RAL 9006
Black RAL 9005 (optional)
RAL 9005
White RAL 9010 (optional)
RAL 9010
Marine Grade treatment
None
Yes
IP protection rating
65
Sizes l x p x h (mm)
612x204x320
Weight (Kgs)
16
