Technical specification
| Lighting source | |
|---|---|
LED type
|
RGBW/FC (20W)
|
Number of LEDs
|
1 (20W)
|
LED expected lifetime (hrs)
|
50000
|
Lumen max (lm)
|
330
|
Red lumen (lm)
|
60
|
Green lumen (lm)
|
140
|
Blu lumen (lm)
|
20
|
White lumen (lm)
|
130
|
| Optics | |
Lenses
|
10°
25°
40°
60°
|
Filters
|
None
f 17° tilt
f34° tilt
f 60°
f 65°
f 100°
f 10°x 60°
|
| Control | |
Control type
|
External Control Driver
|
| Power supply | |
Input range
|
5,5 VDC
|
Power max (W)
|
6
|
| Physical | |
IP protection rating
|
67
68 optional
|
IK grade protection
|
08
|
Dimensions d x h (mm)
|
130 x 42
|
Weight (Kgs)
|
0,9
|
Materials
|
Ultra clear 10mm tempered glass
|
Mounting systems
|
Inground
|
| Finishings | |
Case
|
AISI 304 (standard)
AISI 316 (optional)
Aluminium (optional)
Aluminium - Marine Grade (optional)
|
