Product Description
Downloads
Technical specification
| Lighting source | |
|---|---|
LED type
|
WHITE 2700K
WHITE 3000K
WHITE 4000K
WHITE 6500K
|
Number of LEDs
|
80 White (5W)
|
Lumen max (lm)
|
20000
|
| Optics | |
Lenses
|
8°
15°
15°x30°
25°
40°
60°
|
| Control | |
Control type
|
DMX - RDM
|
| Functions and Setup | |
Functions
|
RDM/DRS
|
| Power supply | |
Input range
|
100 - 240 VAC; 47/63 Hz
|
Power max (W)
|
145
|
| Physical | |
Mounting systems
|
Surface
Truss (optional)
|
Colour finishing
|
Grey RAL 9006 (standard)
RAL 9006
Black RAL 9005 (optional)
RAL 9005
White RAL 9010 (optional)
RAL 9010
|
IP protection rating
|
20
|
Sizes l x p x h (mm)
|
520 x 236 x 143
|
Weight (Kgs)
|
9,2
|
Marine Grade treatment
|
None
|
