Product Description
Downloads
Technical specification
| Lighting source | |
|---|---|
LED type
|
CW+WW (5W)
|
Number of LEDs
|
42x2 Cool White + 42x2 Warm White
|
Lumen max (lm)
|
7800
|
| Optics | |
Lenses
|
120° beam
|
| Control | |
Control type
|
DMX - RDM
|
| Functions and Setup | |
Functions
|
RDM/DRS
|
| Power supply | |
Input range
|
Universal 100 - 240 VAC; 50/60 Hz
|
Power max (W)
|
60
|
| Physical | |
Mounting systems
|
Surface
Truss (optional)
|
Colour finishing
|
Grey RAL 9006 (standard)
RAL 9006
Black RAL 9005 (optional)
RAL 9005
White RAL 9010 (optional)
RAL 9010
|
Marine Grade treatment
|
None
Yes
|
IP protection rating
|
67
|
Sizes l x p x h (mm)
|
1481 x 93 x 115
|
Weight (Kgs)
|
xxx
|
