Technical specification
LED type
RGBW5050MULTICHIP
Number of LEDs
15
LED expected lifetime (hrs)
50000
Lumen MAX
9580
Red lumen (lm)
2080
Green lumen (lm)
3750
Blu lumen (lm)
640
White lumen (lm)
3750
Colour temperature range (K)
2000 - 10000
Lenses
10°
25°
40°
60°
Filters
None
f 60°
f 100°
f 6°x 60°
Control type
DMX - RDM
DMX - RDM + Wireless (on request)
Functions
RDM/DRS
RDM/DRS + touch control panel
Wireless DMX receiver
Input range
100 - 277 VAC; 47/63 Hz
Power (W)
120
Mounting systems
Surface
Truss (optional)
Colour finishing
Grey RAL 9006 (standard)
RAL 9006
Black RAL 9005 (optional)
RAL 9005
White RAL 9010 (optional)
RAL 9010
Any RAL (optional)
Marine Grade treatment
None
Yes
IP protection rating
67
Sizes l x p x h (mm)
925 x 163 x 160
Weight (Kgs)
6,7
