Product Description
Downloads
Technical specification
| Lighting source | |
|---|---|
LED type
|
RGBW5050MULTICHIP
|
Number of LEDs
|
20
|
LED expected lifetime (hrs)
|
50000
|
Lumen MAX
|
12780
|
Red lumen (lm)
|
2780
|
Green lumen (lm)
|
5000
|
Blu lumen (lm)
|
860
|
White lumen (lm)
|
5000
|
Colour temperature range (K)
|
2000 - 10000
|
| Optics | |
Lenses
|
6°
10°
25°
40°
60°
|
Filters
|
f 60°
f 100°
f 6°x 60°
|
| Control | |
Control type
|
DMX - RDM
DMX - RDM + Wireless (on request)
|
| Functions and Setup | |
Functions
|
RDM/DRS
RDM/DRS + touch control panel
|
| Power supply | |
Input range
|
100 - 277 VAC; 47/63 Hz
|
Power (W)
|
160
|
| Physical | |
Mounting systems
|
Surface
Truss (optional)
|
Colour finishing
|
Grey RAL 9006 (standard)
RAL 9006
Black RAL 9005 (optional)
RAL 9005
White RAL 9010 (optional)
RAL 9010
Any RAL (optional)
|
Marine Grade treatment
|
None
Yes
|
IP protection rating
|
67
|
Sizes l x p x h (mm)
|
1222 x163 x 160
|
Weight (Kgs)
|
8,6
|
