Product Description



Downloads
Technical specification
LED type
RGBW5050MULTICHIP
Number of LEDs
25
LED expected lifetime (hrs)
50000
Lumen MAX
14170
Red lumen (lm)
2920
Green lumen (lm)
5750
Blu lumen (lm)
840
White lumen (lm)
5500
Lenses
15°
15°x30°
25°
40°
60°
Filters
None
f 60°
f 100°
f 8°x 60°
Control type
DMX - RDM
DMX - RDM + Wireless (on request)
Functions
RDM/DRS + touch control panel
Wireless DMX receiver
Input range
100 - 277 VAC; 47/63 Hz
Power (W)
175
Inrush current
50A@230V
Mounting systems
Surface
Truss (optional)
Colour finishing
Grey RAL 9006 (standard)
RAL 9006
Black RAL 9005 (optional)
RAL 9005
White RAL 9010 (optional)
RAL 9010
Any RAL (optional)
Marine Grade treatment
None
Yes
IP protection rating
67
Sizes l x p x h (mm)
1517 x 163 x 160
Weight (Kgs)
9,9
