Product Description
Downloads
Technical specification
Lighting source | |
---|---|
LED type
|
CW+WW (5W)
|
Number of LEDs
|
20 (2700K) + 20 (6500K)
|
Lumen MAX
|
10000
|
Optics | |
Lenses
|
8°
15°
15°x30°
25°
40°
60°
|
Filters
|
None
f 60°
f 100°
f 8°x 60°
|
Control | |
Control type
|
DMX - RDM
DMX - RDM + Wireless (on request)
DMX - RDM + DALI
DMX - RDM + DALI + Wireless (on request)
|
Functions and Setup | |
Functions
|
RDM/DRS
|
Power supply | |
Input range
|
100 - 240 VAC; 47/63 Hz
|
Power (W)
|
84
|
Physical | |
Mounting systems
|
Surface
Truss (optional)
|
Colour finishing
|
Grey RAL 9006 (standard)
RAL 9006
Black RAL 9005 (optional)
RAL 9005
White RAL 9010 (optional)
RAL 9010
|
Marine Grade treatment
|
None
Yes
|
IP protection rating
|
67
|
Sizes l x p x h (mm)
|
1484 x 93 x 115 mm
|
Weight (Kgs)
|
xxx
|
