Product Description



Downloads

UM_AB SL150_art-1840_low.pdf

ART.184017 - ARCHIBAR SL 150 RGBW 150CM.zip
Technical specification
LED type
RGBW5050MULTICHIP
Number of LEDs
20
LED expected lifetime (hrs)
50000
Lumen MAX
7090
Red lumen (lm)
1300
Green lumen (lm)
3070
Blu lumen (lm)
440
White lumen (lm)
2700
Lenses
15°
15°x30°
25°
40°
60°
Filters
None
f 17°
f 34°
f 8°x 60°
Control type
DMX - RDM
DMX - RDM + Wireless (on request)
Functions
RDM/DRS
Wireless DMX receiver
Input range
100 - 240 VAC; 47/63 Hz
Power (W)
110
Mounting systems
Surface
Truss (optional)
Colour finishing
Grey RAL 9006 (standard)
RAL 9006
Black RAL 9005 (optional)
RAL 9005
White RAL 9010 (optional)
RAL 9010
Marine Grade treatment
None
Yes
IP protection rating
67
Sizes l x p x h (mm)
1484 x 93 x 115 mm
Weight (Kgs)
xxx
