Product Description
Downloads
Technical specification
| Lighting source | |
|---|---|
LED type
|
RGBW5050MULTICHIP
|
Number of LEDs
|
10
|
Lumen MAX
|
4550
|
Red lumen (lm)
|
800
|
Green lumen (lm)
|
1900
|
Blu lumen (lm)
|
300
|
White lumen (lm)
|
1850
|
| Optics | |
Lenses
|
Narrow
Medium
Wide
Ultra Narrow
10°x60°
|
| Control | |
Control type
|
DMX - RDM
DMX - RDM + Wireless (on request)
|
| Functions and Setup | |
Functions
|
RDM/DRS
|
| Power supply | |
Input range
|
100 - 240 VAC; 47/63 Hz
|
Power (W)
|
110
|
| Physical | |
Mounting systems
|
Surface
Truss (optional)
|
Colour finishing
|
Black RAL 9005 (standard)
RAL 9005
Grey RAL 9006 (optional)
RAL 9006
White RAL 9010 (optional)
RAL 9010
|
Marine Grade treatment
|
None
Yes
|
IP protection rating
|
67
|
Sizes l x p x h (mm)
|
1012 x 163 x 185
|
Weight (Kgs)
|
7,3
|
